Power over Ethernet: Past, Present, and Future

Power over Ethernet: Past, Present, and Future

Aug. 16, 2017
Why do standards and certified PoE devices matter, and what we can expect from the technology down the road?

Download this article in PDF format.

Power over Ethernet (PoE) has become the colloquial term used to describe any technology that allows an Ethernet device to transmit and receive data, as well as receive power over the same cabling. The benefits of using the same cable for both data and power are numerous. It allows power to be delivered to small devices without having an electrician wire new circuits or a transformer to convert ac to dc—also referred to as a wall wart. It can also reduce the weight and cost of deployments, and when using standardized technology, it ensures a high level of safety.

However, when it comes to how PoE works from a user’s standpoint, the general term “PoE” could actually represent any number of different, incompatible technologies, which has led to considerable market confusion. To help overcome this turmoil, the Ethernet Alliance, an industry forum that aims to advance and promote IEEE Ethernet standards, is launching a certification program that will enable manufacturers to complete certification requirements to earn a  branded logo. The goal is to provide a simple and easy way for users to identify what PoE products will work with each other and promote interoperability in the marketplace.

The Past

Many different implementations of PoE have been used over the past 20 years. Generally speaking, the different forms of PoE can be placed into two categories: standardized and proprietary. To help put this into context, here’s a brief history of the technology itself and how it evolved.

The advent of PoE was most commonly referred to as “power injection.” These “power injectors” operated simply by providing power, either ac or dc current, on Ethernet cabling without any true intelligent protocol or safety considerations.

There are many variants of power injectors, but probably the most common involved using the “spare” pairs not utilized by 100Base-TX Ethernet to inject the power. This method can damage or destroy devices that weren’t designed to accept power, and as such, couldn’t be considered a sustainable method of delivering power over data-communications cabling. The next natural step for the IEEE 802.3 Working Group, which defines and revises the standard commonly referred to as “Ethernet,” was to begin work on an inherently safe way to deploy PoE.

The IEEE 802.3 Working Group began its first PoE project in 1999: IEEE 802.3af, under the cumbersome title “Clause 33. Data Terminal Equipment (DTE) Power via Media Dependent Interface (MDI),” was eventually ratified in 2003. It defined Power Sourcing Equipment (PSE) that delivered power, and Powered Devices (PDs) that received power.

The 802.3af standard allowed for delivery of up to 13 W of power to a PD utilizing just two of the available four twisted pairs in Ethernet cabling. It also provided additional freedom in which you could physically place a PD, as designed, to support the entire 100-meter reach of the most common Ethernet speeds.  While this may not seem like a lot of power, it was adequate for many applications, including Voice over Internet Protocol (VoIP) telephones, stationary IP cameras, door access control units, low-power wireless access points, and many others.

PoE Powers Up to 25.5 W

Despite the popularity of the standard, many devices require more than 13 W for their intended application. The natural evolution was to allow more power in order to unleash these additional PoE applications. The IEEE 802.3 Working Group ratified its second PoE standard, IEEE 802.3at, in 2009. While still only delivering power over two pairs, it altered the original standard by adding an additional power class that delivered up to 25.5 W to a PD. This allowed for pan and tilt cameras and other devices with similar power requirements to take advantage of a standardized technology.

Once IEEE 802.3af and IEEE 802.3at became entrenched, a call for even more power started to emerge. Several different proprietary forms of the technology, which were typically based on the IEEE specification, came into existence and increased available power to PDs by delivering power over all four twisted pairs. Again, these proprietary technologies used variations on the commonly known PoE term. It is important to note that since these were proprietary technologies, they by definition did not ensure interoperability, which added to the confusion of what a PoE-branded device actually meant to the end user.

The Present

Armed with the brief history of these technologies, it is clear that the term PoE was and still is used by many different organizations to refer to technologies that aren’t always interoperable with each other. This is especially apparent on the marketing and packaging of products using the term PoE. It has been all too common that a user purchases a PSE and PD with PoE branding, only to quickly find that the PD doesn’t receive the required power for its application, or that the PD doesn’t receive power all together.

The Ethernet Alliance PoE Certification Program, which will launch in Fall 2017, is designed to address these problems. It will initially focus on IEEE 802.3af and IEEE 802.3at products, since so many are currently deployed and will continue to be used in the future. The PoE Certification Program will eliminate confusion and interoperability concerns for end users simply by verifying that PSEs and PDs will work properly together. All products that successfully pass the specified requirements will receive a certified PoE logo to provide peace of mind to users.

The Future

As one could deduce from the history of PoE to present day, there’s a seemingly perpetual desire for additional power as device applications in this space continue to broaden. With that said, the time has arrived once again for a standardized solution for additional power.

In 2014, the IEEE 802.3 Working Group approved additional work to achieve this goal with the project titled IEEE 802.3bt. This project will standardize the method of utilizing all four twisted pairs to deliver up to 71 W to a PD. IEEE 802.3bt is still in draft form but nearing completion, with a targeted finish date in early 2018.

Due to growing power requirements, the Ethernet Alliance Certification Program has been designed with the evolution of IEEE 802.3 PoE standards in mind, and will be expanded to support upcoming IEEE PoE standards like IEEE 802.3bt.

About the Author

Craig Chabot | Manager, Wireless and Power over Ethernet Testing Services Groups

Craig Chabot is the Manager of the Wireless and Power over Ethernet (PoE) Testing Services Groups at the University of New Hampshire InterOperability Laboratory (UNH-IOL). As an undergrad at UNH, Craig began work at the UNH-IOL in 2008 in the Wireless Group, where he gained knowledge in computer networking, testing methodologies, and the IEEE 802.11 standard.

After obtaining his Bachelors of Science in Mathematics in 2011, Craig continued work in the Wireless Group, furthering his understanding of IEEE 802.11 in addition to developing new testing services for the group. In the fall of 2013, Craig took on his new role leading the Wireless Testing Services.

In 2015, Craig joined the Broadband Industry at the UNH-IOL to assist with operations and began managing the PoE group. Craig regularly attends IEEE 802.3 meetings and has contributed as PICS editor to IEEE 802.3bu and IEEE 802.3bt working groups.
